10' x 10' Octagonal Storage Shed (72 sq.ft.)
USI Product Code
E73
Dimensions
8' (H) x 10' x 10' (ID)
2.4m (H) x 3050mm x 3050mm (ID)
Weight
25960 lbs
11800 kg
Shop Drawings
Click on image to enlarge.
Plan View
Front View
Side View
Construction Details
- AVAILABLE IN VARIOUS COLORS & FINISHES
- CAN BE PAINTED OR SEALED WITH ANTI-GRAFFITI
- ALL CORNERS CHAMFERED
- STEEL REINFORCED 127mm [5"] WALLS
- 2160mm [85"] OF HEADROOM
- SEE GENERAL NOTES FOR HARDWARE
CSA Details
CSA 23.4-05
- 35 MPa (5000psi) AT 28 DAYS
- STRIPPING STRENGTH: MIN. 20 MPa (2900psi)
- 5-8% AIR ENTRAINED
- EXPOSURE CLASS: C-1
REINFORCING: STEEL TO CSA CAN A23.1
General Notes
- TWO [8" x 8"] ALUMINUM LOUVER VENTS
- C/W NON REMOVABLE PIN (NRP) HINGES
- COMMERCIAL KEYED DEAD BOLT
- CORROSION-RESISTANT DOUBLE DOOR
- DOOR OPENING SIZE = 61" (W) x 82" (H)
Available Options
- CUSTOM COLOURS OR FINISHES
- CUSTOM HARDWARE AVAILABLE UPON REQUEST
